VSG module – Print with the utmost precision on thin materials.
VSG module
The VSG module is a versatile tool equipped with a vacuum table and temperature control function. The module makes it possible to print on materials that are difficult to print on, such as thin substrates, materials that are easily deformed, and materials on which the print quality is dependent on temperature.
Compatible with:
Discover all the advantages of VSG in your company!
A simple solution to support IMAGO digital printers
The device’s design is aesthetically pleasing and user-friendly, while operation and service are extremely economical. When not in use, the VSG shuts down automatically, which contributes to lower operating costs. Individual functions are adjusted with just three buttons, making the device easy to operate.
Suction table for UV LED and Nanosolvent printers
The VSG module automatically smooths the substrate during printing and allows supporting thin materials increasing the precision and repeatability of UV LED prints on paper, film, sheet metal, plywood or fabric. At the same time, it prevents deformation of details under the heat of the UV LED lamp, making it easier to print on Plexiglas, PVC and other plastics.
High precision printing in anodized aluminum
The temperature function in printing on anodized aluminum sheet increases the achievable color saturation and resolution of prints by evaporating excess ink. At the same time, the suction table increases the precision of prints by stabilizing the sheet metal on the work table.
Printing capabilities on plastic chocolate
For food printers, VSG enhances the quality of printing on chocolate and enables plastic molding after printing. Sucking, on the other hand, allows printing on sugar paper and transfer film.
Choose VSG module and enjoy additional printer features
Learn more about VSG’s capabilities
VSG for industry
VSG for confectionery
VSG and UV LED printers
- Smoothing the substrate (printing on fabrics, printing on leather)
- Protection against deformation of the product under the influence of UV LED lamp (printing on plexiglass, printing on PVC)
- Stabilization of the substrate (printing on film, printing on paper, printing on sheet metal)
- Increasing the precision of printing
VSG and food printers
- Stabilization of sheets of transfer film or sugar paper
- Possibility of printing on semi-liquid chocolate
- Increasing color saturation
printing
VSG and printers for aluminum
- Increase printing precision
- Increasing color saturation
- Stabilization of the aluminum sheet
VSG and Nanosolvent printers
- Smoothing the substrate (printing on leather, printing on fabrics)
- Substrate stabilization (printing on paper, printing on plywood)
- Increasing the precision of printing
- Acceleration of ink evaporation
Technical specifications – VSG module
| Model | VSG |
| External dimensions | 33,6 cm x 78, 6 cm x 8,6 cm |
| Work table dimensions | 32 cm x 65 cm |
| Voltage | 230V |
| Power consumption | 400 W |
| Weight | 12 kg |
| Maximum height of print product after VSG application | 6,4 cm |
| Maximum heating temperature | 55 °C |
Accessories VSG
